Lam Rainbow 4525I Oxide Etcher

Lam Rainbow 4525I Oxide Etcher

Lam Rainbow 4525I Oxide Etcher

Lam Rainbow 4525I Oxide Etcher,Envision Software, version E1.6-011 Release, SECS Interface, Mechanical Clamping system, Bottom Actuated Clamp, In USA

Category: Others

Description

Description

Model:Lam Rainbow 4525I

The item is only for end user. The item is subject to prior sale without notice.

Category: Plasma Etch

Original Equipment Manufacturer: Lam Research

Condition: Good Condition,. Sell it at AS IS,WHERE IS condition or complete,working, fully tested condition

Quantity: 1 set

Wafer Size: 8-inch

Valid Time: Subject to prior sale

Lead Time: TBD

Location:Morgan Hill,CA95037,USA

Warranty: TBD

Refund: N/A

Inspection: N/A

Installation and training: Yes at extra cost.

Description:

Envision Software, version E1.6-011 Release
SECS Interface
Mechanical Clamping system
Bottom Actuated Clamp
Orbital gas panel
Download recipe: Yes
Heating of exhausts: ISO
MTBC: 75 RF Hours
Generator: PDW2200
Match:LoFAT
ISO Match:Yes
ISO Generator: AW1250
ISO Heated Paddle
Throttle Valve: Main chamber and ISO chamber
Variable Gap
Wafer Area Pressure (WAP) Manometer
Hines Indexers
Exit load lock wafer sensor
End point detection: Single EP200 Monochromator
Temperature control
Lower electrode temperature: 10C
Upper electrode temperature: 40C
Ballast and crossover
Crossover gas number: 1
Crossover gas flow: 300
Ballast gas number: 1
Ballast gas flow: 300
Gases:
- Gas 1 Ar 1000SCCM
- Gas 2 CF4 100SCCM
- Gas 3 CHF3 100SCCM
- Gas 4 He 500SCCM
- Gas 5 SF6 100SCCM
- Gas 6 N2 100SCCM
- Gas 7
- Gas 8 NF3 1000SCCM
- Gas 11 He 500SCCM
- Gas 12
- Chamber clamp flow: 50SCCM
- Chamber clamp pressure: 50 Torr

The item is only for end user. The item is subject to prior sale without notice.

SS5816

All the Lam Plasma Etcher equipment trademarks belongs to Lam Research , the original equipment manufacturer. All rights reserved.
